16/70-20 EM 14 PR ALLIANCE 326 WIDE GRIP 149B/166A2 E-2/G-2/L-2 TL

Description

The Alliance 326 Wide Grip has been designed for use on loader dozers and dump trucks working in construction and industrial applications. An aggressive tread pattern provides high traction under demanding surface conditions coupled with good self-cleaning properties. A strengthened heavy-duty casing used in the wide-base tyre offers improved stability during service and a special ozone-resistant compound used in the manufacturing process adds durability and further extends the tyre's life cycle when used in all off-road environments.

Features

  • Bias ply tyre for dump trucks and loader dozers working in earthmoving applications.
  • Impressive traction and good self-cleaning properties.
  • Heavy-duty casing for increased stability and robustness.

Specification

Application
PLANT
Size
16/70-20 EM
Size Suffix
EARTHMOVER
Equivalent Size 1
405/70-20
Brand
ALLIANCE
Pattern
326 WIDE GRIP
Load/Speed Index
149B/166A2
Ply Rating
14
TT/TL
TL
Construction
BIAS
Nominal Section Width
16
Profile
70
Rim
20
TRA
E-2/G-2/L-2
Recommended Rim
13
Section Width
407 mm
Overall Diameter
1076 mm
Static Load Radius
475 mm
Rolling Circumference
3130 mm
Tread Depth
24.50 mm
Max Load (KG)/Speed (KM/H) 1
3250/50 WHEN 3.50 BAR (E-2)
Max Load (KG)/Speed (KM/H) 2
5300/10 WHEN 4.50 BAR (L-2)
